| Specifications |
|
| Voltage AC |
APPA 61, 62, 62R, 62T
Range: 200.0mV~750V
Basc Accuracy: +/-(1.5%+5d) At 50Hz~500Hz
Input Impedance: 10M?//100pF
Overload Protection 750V Rms
Conversion Type: Average Sensing RMS Indicating
|
| Voltage DC |
APPA 61, 62, 62R, 62T
Range: 200.0mV~1000V
Basc Accuracy: +/-(0.5%+5d)
Input Impedance: 10M?
Overload Protection 1000V DC
Conversion Type: Average Sensing RMS Indicating
|
| Current AC |
APPA 62, 62R, 62T
Range: 2.000, 10.00A
Basc Accuracy: +/-(1.5%+5d) At 50Hz~500Hz
Input Protection: 10A/500V Fast Blow Fuse For A Input
Conversion Type: Average Sensing RMS Indicating
|
| Current DC |
APPA 62, 62R, 62T
Range: 2.000, 10.00A
Basc Accuracy: +/-(1.0%+3d)
Input Protection: 10A/500V Fast Blow Fuse For A Input
|
| Resistance |
APPA 61, 62, 62R, 62T
Range: 200.0?~20M?
Basc Accuracy: +/-(0.7%+2d)
Overload Protection: 600V Rms
|
| Continuity Beeper |
APPA 61, 62, 62R, 62T
<150?, 2k Hz Tone Buzzer
|
| Diode Test |
APPA 61, 62, 62R, 62T
Open Circuit Voltage: 2V
|
| Frequency Counter |
APPA 62, 62R, 62T
Range: 2000Hz~20MHz
Basc Accuracy: +/-(0.01%+1d) <1.5V Ac Rms, <5V Ac Rms
Overload Protection: 600V Rms
|
| Capacitance |
APPA 62, 62R, 62T
Range: 2.000nF~2.000mF
Basc Accuracy: +/-(1.9%+8d)
Overload Protection: 600V Rms
|
| Temp. |
APPA 62T
Range: -20?~800?, -4?~ -1472?
Basc Accuracy: +/-(1.0%+3?)
Overload Protection 600V Rms
|
|
| General Specifications |
|
| Sampling Rate |
1.5times/Sec
|
| Overload Indication |
"OL", "-OL"
|
| Lowe Battery Indication |
|
| Auto Power Off |
Approx. 10 Minutes
|
| Operating Temperature |
-20?~ 50?, <80% RH
|
| Storage Temperature |
-20?~ 60?
|
| Temperature Coefficient |
0.15(Spec. Acc)/?, <18? Or >28?
|
| Safety |
IEC61010 And Designed To Meet UL61010 Specifications
|
| Power Requirement |
IEC LR03, AM4 Or AAA Size 1.5V X 2
|
| Battery Life |
250 Hours (Alkaline Battery)
|
| Size |
74mm (W) X 156mm (L) X 44mm (H)
|
| Weight |
250 Grams
|
| Included With Instrument |
APPA 61, 62, 62R
Test Leads, ZnC Battery (Installed) And Manual
APPA 62T
Test Leads, ZnC Battery (Installed), Temp. Adaptor, Bead Probe,
And Manual |
|
